Lead to lithium battery
| LiFePO4 Battery Bank 12.8V Battery Bank assembled with enclosure, optional BMS and plug & play interface - for Renewable Energy & Backup Power Applications & replacement of SLA battery ApplicationsReplacement for Sealed Lead Acid Battery (SLA).Battery Storage Systems for Solar System such as street lamp. |
|
| Battery Type | Nominal voltage | Nominal capacity | Energy power | Dimension(L*W*H) | Net weight |
| 6.4V4AH | 6.4V | 4AH | 25.6WH | 70*47*101mm | 0.3kg |
| 6.4V5AH | 6.4V | 5AH | 32WH | 70*47*101mm | 0.35kg |
| 6.4V6AH | 6.4V | 6AH | 38.4WH | 70*47*101mm | 0.4kg |
| 6.4V7AH | 6.4V | 7AH | 44.8WH | 151*34*94mm | 0.5kg |
| 6.4V8AH | 6.4V | 8AH | 51.2WH | 151*34*94mm | 0.55kg |
| 6.4V10AH | 6.4V | 10AH | 64KWH | 151*50*94mm | 0.65kg |
| 6.4V12AH | 6.4V | 12AH | 76.8WH | 151*50*94mm | 0.7kg |
| 12.8V4AH | 12.8V | 4AH | 51.2WH | 90*70*101mm | 0.6kg |
| 12.8V4.5AH | 12.8V | 4.5AH | 57.6WH | 90*70*101mm | 0.65kg |
| 12.8V5AH | 12.8V | 5AH | 64WH | 90*70*101mm | 0.7kg |
| 12.8V6AH | 12.8V | 6AH | 76.8WH | 151*65*94mm | 0.8kg |
| 12.8V7AH | 12.8V | 7AH | 89.6WH | 151*65*94mm | 1kg |
| 12.8V8AH | 12.8V | 8AH | 102.4WH | 151*65*94mm | 1.1kg |
| 12.8V9AH | 12.8V | 9AH | 115.2WH | 151*65*94mm | 1.2kg |
| 12.8V10AH | 12.8V | 10AH | 128WH | 151*65*94mm | 1.33kg |
| 12.8V12AH | 12.8V | 12AH | 153.6WH | 151*100*95mm | 1.41kg |
| 12.8V15AH | 12.8V | 15AH | 192WH | 181*77*167mm | 1.55kg |
| 12.8V18AH | 12.8V | 18AH | 230.4WH | 181*77*167mm | 1.8kg |
| 12.8V20AH | 12.8V | 20AH | 256WH | 181*77*167mm | 2.0kg |
| 12.8V25AH | 12.8V | 25AH | 320WH | 166*175*125mm | 2.7kg |
| 12.8V30AH | 12.8V | 30AH | 384WH | 195*130*155mm | 3.5kg |
| 12.8V40AH | 12.8V | 40AH | 512WH | 197*165*170mm | 4.5kg |
| 12.8V50AH | 12.8V | 50AH | 640WH | 229*138*210mm | 5.5kg |
| 12.8V65AH | 12.8V | 65AH | 832WH | 350*167*180mm | 6.8kg |
| 12.8V70AH | 12.8V | 70AH | 896WH | 260*169*210mm | 7.5kg |
| 12.8V80AH | 12.8V | 80AH | 1024WH | 260*169*210mm | 8.5kg |
| 12.8V88AH | 12.8V | 88AH | 1126.4WH | 306*169*210mm | 8.7kg |
| 12.8V100AH | 12.8V | 100AH | 1280WH | 110*395*288mm | 10.3kg |
| 12.8V100AH | 12.8V | 100AH | 1280WH | 329*173*216mm | 10.3kg |
| 12.8V120AH | 12.8V | 120AH | 1536WH | 406*173*238mm | 12.5kg |
| 12.8V150AH | 12.8V | 150AH | 1920WH | 485*170*240mm | 15.0kg |
| 12.8V180AH | 12.8V | 180AH | 2304WH | 381*193*250mm | 18.0kg |
| 12.8V200AH | 12.8V | 200AH | 2560WH | 522*240*218mm | 20.3kg |
| 12.8V230AH | 12.8V | 230AH | 2944WH | 522*240*218mm | 22.0kg |
| 12.8V280AH | 12.8V | 280AH | 3584WH | 520*269*220mm | 26.5kg |
| 12.8V300AH | 12.8V | 300AH | 3840WH | 520*269*220mm | 27.5kg |
| 12.8V320AH | 12.8V | 320AH | 4096WH | 520*269*220mm | 28.5kg |
| 12.8V400AH | 12.8V | 400AH | 5120WH | 520*269*220mm | 36.3kg |
| 25.6V15AH | 25.6V | 15AH | 384WH | 166*175*125mm | 3.5kg |
| 25.6V20AH | 25.6V | 20AH | 512WH | 195*130*155mm | 4.5kg |
| 25.6V25AH | 25.6V | 25AH | 640WH | 197*165*170mm | 6.5kg |
| 25.6V30AH | 25.6V | 30AH | 768WH | 197*165*170mm | 7.5kg |
| 25.6V40AH | 25.6V | 40AH | 1024WH | 229*138*210mm | 9.0kg |
| 25.6V50AH | 25.6V | 50AH | 1280WH | 260*169*210mm | 10.2kg |
| 25.6V65AH | 25.6V | 65AH | 1664WH | 406*173*238mm | 13.0kg |
| 25.6V70AH | 25.6V | 70AH | 1792WH | 329*173*216mm | 14.0kg |
| 25.6V80AH | 25.6V | 80AH | 2048WH | 381*193*250mm | 16.0kg |
| 25.6V88AH | 25.6V | 88AH | 2252.8WH | 485*170*240mm | 17.0kg |
| 25.6V100AH | 25.6V | 100AH | 2560WH | 522*240*218mm | 20.3kg |
| 25.6V120AH | 25.6V | 120AH | 3072WH | 522*240*218mm | 24.0kg |
| 25.6V150AH | 25.6V | 150AH | 3840WH | 520*268*220mm | 27.2kg |
| 25.6V200AH | 25.6V | 200AH | 5120WH | 520*268*220mm | 36.3kg |
